HVAC maintenance visit
The maintenance visit, unit by unit: temperature rise, pressures, subcooling and superheat, filters, CO; ducts and dryer vents.
No credit card. Cancel anytime.
Feet and inches or metric: your choice. One switch on the sheet converts every measurement.
What you measure
The template's tables and their columns, as the app shows them. Calculated columns fill in as you type.
Furnaces
- Unit
- FuelChoices: Natural gas Propane Oil Electric
- Make and model
- Filter size
- Filter MERV
- FilterChoices: Replaced Cleaned Checked, still good
- Return air
- Supply air
- Temperature rise calculated
- Rise range, low
- Rise range, high
- Rise margin calculated
- External static pressure
- Maximum static, plate
- Static margin calculated
- Manifold pressure
- Manifold pressure, maker
- Manifold gap calculated
- CO near the unit (ppm)
- VentingChoices: Good To fix
- Condensate drainChoices: Clear Cleaned To fix None
- Notes
Air conditioners and heat pumps
- Unit
- SystemChoices: Central air conditioner Ducted heat pump Ductless heat pump Other
- Make and model
- RefrigerantChoices: R-410A R-454B R-32 R-22 Other
- Metering deviceChoices: TXV or EEV Fixed orifice
- Filter size
- Filter MERV
- FilterChoices: Replaced Cleaned Checked, still good
- Outdoor air
- Return air
- Supply air
- Temperature split calculated
- Liquid line
- Condensing saturation
- Subcooling calculated
- Subcooling target
- Subcooling gap calculated
- Suction line
- Evaporating saturation
- Superheat calculated
- Superheat target
- Superheat gap calculated
- External static pressure
- Maximum static, plate
- Static margin calculated
- CoilsChoices: Clean Cleaned this visit To clean
- Condensate drainChoices: Clear Cleaned To fix None
- Notes
Ducts and registers
- Run or registers
- KindChoices: Supply trunk Supply branches and registers Return trunk Return grilles Exhaust (bathroom, kitchen)
- Duct materialChoices: Sheet metal Flexible Fibrous glass (board or liner)
- Registers or grilles
- Duct length
- Width or diameter
- Height (rectangular duct)
- Inside surface to clean calculated
- Condition seenChoices: Visibly clean Dust and debris Debris blocking the airflow Suspected mould Vermin
- Access openings to cut
- Notes
Dryer vents
- Dryer
- VentChoices: Rigid metal Flexible metal Foil or plastic
- Straight length
- 90° elbows
- Equivalent length per 90° elbow
- 45° elbows
- Equivalent length per 45° elbow
- Equivalent length calculated
- Outside hoodChoices: Box or louvered, damper works Angled, damper works Damper stuck or missing Screen to remove
- Lint in the ventChoices: Light Heavy Blocked
- Notes
About this template
The seasonal visit of a maintenance agreement, one row per unit: the furnace's temperature rise, static and manifold pressure against its rating plate, the air conditioner's or heat pump's subcooling and superheat worked out from your readings against the plate's target, filters, drains and CO.
Guide and sources
One row per unit visited: the furnace in the Heating section, the air conditioner or heat pump in the other. ENERGY STAR asks a pre-season check-up each year, the cooling in the spring and the heating in the fall; the American national standard is ACCA 4 QM. Note the filter, then take the readings once the unit has run steadily.
The furnace: the temperature rise is the supply air less the return air, compared with the rise range on the rating plate; the external static pressure is compared with the plate's maximum; the manifold pressure with the maker's figure for the model and the fuel (Goodman and MRCOOL: within 0.3 in. w.c.). The CO near the unit is noted as read; Health Canada's residential limits are 25 ppm over 1 hour and 10 ppm over 24 hours.
The air conditioner or heat pump: type the line temperatures and the saturation temperatures read on the gauge, and the sheet works out the subcooling and the superheat, compared with the target on the nameplate or the maker's chart (Rheem: ±1.5 °F for subcooling, charged in cooling at 55 °F outdoor and above). Every target comes from the unit's own plate or manual; the sheet shows each margin, never a verdict, and totals nothing. The client's report shows the units, the filters, the rise or the split, the static pressure and what was done; the targets and margins stay in your team's report.
Ducts and vents has a section of its own. The ducts, a row per run or per group of registers: the kind, the material, the registers or grilles, the length and the inside size (a round duct: its diameter only) give the inside surface to clean; note the condition as you see it and the access openings to cut. NADCA ACR asks an inspection before and after the cleaning, and for a house recommends one every year for the air handler and every 2 years for the ducts. The sheet never says ducts need cleaning for health: EPA and CMHC found no proven benefit, and name the cases where cleaning makes sense (mould, vermin, debris, a new house or a renovation, an airflow problem). The dryer vents: the straight length and the elbows, each with its equivalent length from the code table or the maker, give the equivalent length, to compare with the IRC's 35 ft or the dryer maker's chart.
Sources
- US EPA, MERV Government
- ENERGY STAR, maintenance checklist Government
- Rheem, R-454B charging chart Manufacturer data
- Goodman, GMES80 furnace Manufacturer data
- MRCOOL, VersaPro furnace Manufacturer data
- Trane, A801X furnace Manufacturer data
- US EPA, Section 608 Government
- American Standard, 4A6H4 Service Facts Manufacturer data
- NADCA ACR Trade association
- EPA, air duct cleaning Government
- IRC 2021, M1502 Code
- Whirlpool dryer vent chart Manufacturer data
- ACCA 4 QM Standard
- NRCan, Keeping the Heat In, ch. 9 Government
- Health Canada, carbon monoxide Government
- CMHC, heating duct cleaning Government
- Quebec, halocarbons Government
